We use robust, proven technology and combine them to customize your process. You have access to 100% heat power at any given time. The solution has easy access to components for minimal maintenance downtime and cost.
Customized to your needs: select needed charging, discharging and storage size
Allows simultaneous charging and discharging
Provides maximum heat power at all times and reacts to your process peaks
Easy access to components to ensure minimal downtime and cof maintenance
Easy to scale up and benefits increase with size
Customize your needs: select needed charging, discharging and storage size.
Allows simultaneous charging and discharging
Provides maximum heat power at all times and reacts to your process peaks.
Easy access to components to ensure minimal downtime and cof maintenance.
Easy to scale up and benefits increase with size.
Ordinary sand is heated to temperatures of over 1000°C in our patent-pending electric heater with electricity from a renewable energy source or from the grid when prices are low. The hot sand is stored in a specially designed silo that contains no piping or heat transfer components.
As sand is an excellent insulator, the sand is kept stationary while stored to retain heat efficiently. The sand is set in motion when it’s time to transfer the heat. The dynamic sand flow is 10 times more effective in heat transfer than static storage solutions.
When thermal energy is needed, the hot sand flows through our proprietary heat exchanger, where the heat is transferred to a working medium such as steam, superheated steam, thermal oil, hot air, or pressurized hot water depending on process requirements.
The cooled sand is collected in a separate storage silo and returned to the heater for reuse. The solution is pre-tested and even pre-built to minimize disruptions on the site.
Steam up to 550°C
Hot oil up to 350°C
Hot water 50-200°C
Hot air up to 800°C
Hot water 50-200°C
Steam 50-500°C
Hot oil up to 280°C
Hot air 80-800°C
Charger & Discharger 1-20 MW
Storage size 20-500MWh
.jpg)
Customized to your needs. Select charging, discharging and storage size.
DO THE MATH
Charger & Discharger 1-20 MW
Storage size 20-500MWh
